Description
Specs
| 60 Hz | SQ160R |
|---|---|
| BTUs (water temp/ambient air/relative humidity) |
|
| 80/80/80 | 128,000 |
| 80/80/63 | 120,000 |
| 80/50/63 | 78,000 |
| Coefficient of Performance(water temp/ambient air/relative humidity) | |
| 80/80/80 | 5.7 |
| 80/80/63 | 5.5 |
| 80/50/63 Boost Mode | 4.0 |
| Refrigerant | R410A |
| Electrical | |
| Heat or Heat & Cool | H & C |
| kW Input | 6.7 |
| Voltage/Hz/Phase A – 208-230/60/1 E – 380-415/60/3 G – 460/60/3 |
A & B |
| Minimum/Maximum Fuse Size | A – 60 B – 50 |
| Minimum Circuit Ampacity | A – 43.3 B – 31.0 |
| Water Flow *A Heater Bypass Kit is required when flow rates exceed the maximum |
|
| Minimum/Maximum (gpm) | 30/70 |
| Physical | |
| Weight (lbs) | 273 |
| Length x Width x Height (in) | 34″ x 34″ x 40″ |
| Shipping | |
| Weight (lbs) | 304 |
| Length x Width x Height (in) | 37″ x 36″ x 43″ |
Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity. Specifications subject to change.
Features
Discover AquaCal® – Unmatched Pool Heating Efficiency on WholesalePoolHeat.com
Exclusively featured on WholesalePoolHeat.com, AquaCal® is the only heat pump engineered to maximize the energy savings of your variable speed pool pump. Using their patented ThermoLink® Heat Exchanger technology, AquaCal® delivers unique flow characteristics for superior performance.
Enhanced Energy Efficiency
- Optimized Hydraulic Performance:
Their patented design adds only 2 PSI at 45 gpm, ensuring compatibility with both two-speed and variable speed pumps. - Cost-Effective Operation:
- Variable Speed Pumps: Reduces the RPM required to achieve the desired flow rate.
- Single Speed Pumps: Cuts down on run time while maintaining the same pool turnover rate.
Durable, Corrosion-Proof Cabinet
- Engineered for Longevity:
Louvered side panels protect the evaporator coil and ensure efficient air flow. - Built to Withstand the Elements:
Rust and fade-proof, impact resistant, with a built-in drain pan for effective condensate management.
Advanced Microprocessor Control with Digital Display
- Intuitive Operation:
Weather-protected controls with a full-text digital display offer clear menu options and real-time unit status. - Seamless Integration:
Easily connect to most external controllers for both heating and cooling modes. Compatible with the heat pump Smart Controller (HP9) or (HP11).
Smart Pool Management with PoolSync® Technology
- Remote Control & Monitoring:
Adjust heating, cooling, and Auto-Temp modes via the PoolSync® app. Enjoy remote diagnostics, instant performance updates, and quick troubleshooting. - Reliable Performance:
Real-time monitoring ensures your pool heating system operates reliably year-round.
Upgrade to Full Automation
- Effortless Pool Management:
Pair AquaCal® with the PoolSync Relay Center to connect and manage all your pool pad equipment, simplifying your pool care experience.
Experience the innovative performance and energy savings of AquaCal®—now available exclusively on WholesalePoolHeat.com.
Brochures & Manuals
Model Comparison
| 60 Hz | SQ140R | SQ160R | SQ200R | |
|---|---|---|---|---|
| BTUs (water temp/ambient air/relative humidity) |
||||
| 80/80/80 | 114,000 | 128,000 | 138,000 | |
| 80/80/63 | 106,000 | 120,000 | 130,000 | |
| 80/50/63 | 72,000 | 78,000 | 88,000 | |
| Coefficient of Performance (water temp/ambient air/relative humidity) |
||||
| 80/80/80 | 5.7 | 5.7 | 6.1 | |
| 80/80/63 | 5.5 | 5.5 | 5.8 | |
| 80/50/63 | 4.0 | 4.0 | 4.2 | |
| Refrigerant | R410A | R410A | R410A | |
| Electrical | ||||
| Heat or Heat & Cool | H & C | H & C | H & C | |
| kW Input | 5.6 | 6.7 | 6.6 | |
| Voltage/Hz/Phase A – 208-230/60/1 B – 200-230/60/3 G – 460/60/3 |
A & B | A & B | A, B & G | |
| Maximum Fuse Size | A – 60 B – 50 |
A – 60 B – 50 |
A – 60 B – 33.3 G – 25 |
|
| Minimum Circuit Ampacity | A – 38.5B – 31.0 | A – 43.3 B – 31.0 |
A – 42.1 B – 18.4 G – 16.2 |
|
| Water Flow *A Heater Bypass Kit is required when flow rates exceed the maximum |
||||
| Minimum/Maximum (gpm) | 30/70 | 30/70 | 30/70 | |
| Physical | ||||
| Weight (lbs) | 264 | 273 | 310 | |
|
Length x Width x Height (in) |
34″ x 34″ x 40″ | 34″ x 34″ x 40″ | 34″ x 34″ x 40″ | |
| Shipping | ||||
| Weight (lbs) | 304 | 304 | 350 | |
| Length x Width x Height (in) | 37″ x 36″ x 43″ | 37″ x 36″ x 43″ | 37″ x 36″ x 43″ | |
| Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity. Specifications subject to change. | ||||
